| Sr No. | Parameter | Unit | 840/2 | 1260/2 | 1680/2 | 1890/2 | 1260/3 | Test Method : ASTM |
|---|---|---|---|---|---|---|---|---|
| 1 | Cable Twist | TPM | 450 ± 15 | 380 ± 15 | 320 ± 15 | 320 ± 15 | 300 ± 20 | D885 |
| 2 | Moisture Regain | % | Max. 1.0 | Max. 1.0 | Max. 1.0 | Max. 1.0 | Max. 1.0 | D885 |
| 3 | Breaking strength | Kgs | Min 14.0 | Min 21.0 | Min 27.0 | Min 31.50 | Min 31.50 | D885 |
| 4 | EASL @ 4.5 Kgs | % | 9.0 ± 1.0 | - | - | - | - | D885 |
| 5 | EASL @ 6.8 Kgs | % | - | 9.0 ± 1.0 | - | - | - | D885 |
| 6 | EASL @ 9.0 Kgs | % | - | - | 9.0 ± 1.0 | - | - | D885 |
| 8 | EASL @ 11.34 Kgs | % | - | - | - | - | 9.50 ± 1.0 | D885 |
| 9 | Elongation at break | % | Min.20.0 | Min.20.0 | Min.20.0 | Min.20.0 | Min.20.0 | D885 |
| 10 | Thermal Shrinkage (Testrite) @160°C,2mins.,0.05gpd, W/Shield |
% | 4.0-6.0 | 4.0-6.0 | 4.0-6.0 | 4.0-6.0 | 4.0-6.0 | D4974 |
| 11 | Cord Gauge | mm | 0.55 ± 0.03 | 0.63 ± 0.03 | 0.72 ± 0.03 | 0.82 ± 0.03 | 0.80 ± 0.03 | D885 |
| 12 | Dip Pick Up | % | 4.5-5.5 | 4.5-5.5 | 4.5-5.5 | 4.5-5.5 | 4.5-5.5 | D885 |
| 13 | Stiffness | g / 10cords. | Max.40 | Max.50 | Max.65 | Max.75 | Max.75 | D885 |
| 14 | H-Adhesion @160°C, 20 mins, 3 mPa | Kgs./9.5mm | Min.12.0 | Min.14.0 | Min.15.0 | Min.16.0 | Min.16.0 | D 4776 |
Remarks :
- AIT uses own rubber compound for testing H-adhesion
- AIT shall meet the following customer specific requirements:
- Weft material – such as cotton, polyester-cotton, Nylon-cotton extensible type
- Weft density – picks per inch of body and header
- Warp density – Number of ends
- Width and length of the dipped fabric
- Shell roll dimensions and material
